GE BiliSoft 2.0 Phototherapy System

Original price was: $4,674.20.Current price is: $3,973.07.

SKU # 2106573-001

Materials Included

BiliSoft Phototherapy System
(1) Small or Large Pad
(1) Power Cord
User Manual

Note: The disposable pad covers are sold separately.

Product Description

Bilisoft USA

This product cannot ship to a hospital; it can only ship to a small medical practice.

The BiliSoft™ 2.0 Phototherapy System helps provide family-centered care virtually anywhere – in the NICU, pediatrics units, well-baby nurseries, and even at home.

Features and Benefits

Patient Comfort
- Comfort is the keyword, whichever cover options you select. The flat, cushioned BiliSoft 2.0 cover lets you swaddle baby and phototherapy pad together. The BiliSoft 2.0 nest offers sick babies the boundaries and support they need.
- If a baby cannot be swaddled, positioning aids may be placed under the pad to bring more light to the sides of a baby’s body for greater skin surface area exposure to the light
Healing Light, Right Where It’s Needed
- BiliSoft 2.0 delivers phototherapy anywhere – in the Neonatal ICU, Pediatrics, Well Baby Nursery or at home. BiliSoft 2.0 can be used with a radiant warmer, incubator, bassinet, crib, or while in a caregiver’s arms.
BiliSoft 2.0 Fiberoptic Pad Covers
- Ultra-soft, disposable BiliSoft 2.0 covers are made of flame-retardant, skin-friendly fabric
- BiliSoft 2.0 pad covers and nests have soft straps which help swaddle a baby in comfort and transmit phototherapy light too, if an additional overhead phototherapy source is required.
Easy Positioning
- A long, flexible, fiberoptic cable makes positioning easier than ever
Exceptional Coverage
- Provides greater surface area than other fiber-optic devices and many overhead lamps. The pad design also helps to eliminate distance deficiencies.
Conserve space, energy, and lower maintenance costs
- Small footprint and lightweight design, allows easy mounting to a bed or roll stand. Providing flexibility and conservation of space.
Increased Body Surface Exposure The BiliSoft 2.0 can be used with the Giraffe Blue Spot PT Lite for effective phototherapy and increased body surface exposure. GE offers a complete portfolio of phototherapy products for treatment of hyperbilirubinemia – meeting the AAP Guidelines for intensive phototherapy.
Long lasting LED Light
- The units host a long-lasting blue LED light that provides more than 50,000 hours of light therapy
Available with small or large pad

Technicial Specifications

Electrical Specifications
- Input
  - 0.25A – 0.75A @ 100-240V~, 50/60Hz
  - +10%, -15% (Lowest line 85 VAC)
- Leakage Touch Current: Allowable values are 100 μA in normal condition and 500 μA in single fault condition @ 264 V~
Environmental Operating Conditions
- Temperature: +5°C to +35°C (41°F to 95°F)
- Humidity: 15% to 90% RH, non-condensing, but not requiring a water vapor partial pressure > 5 kPa
- Atmospheric Pressure: 70 kPa to 106 kPa (10,000 ft. to -1,250 ft.)
- Light Box: IP21
- Light Pad: IPX4
Storage Requirements
- Temperature: -25°C to +5°C (-13°F to 41°F) without humidity control
- Temperature: +5°C to +35°C (41°F to 95°F) up to 90% RH, non-condensing
- Temperature: +35°C to +70°C (95°F to 158°F) at a water vapor pressure up to 5 kPa
Performance Specifications
- Spectral irradiance (bare fiber optic pad)
  - Large fiberoptic pad – 49 μW•cm-2•nm-1 (+/- 25%) 9-point check
  - Small fiberoptic pad – 70 μW•cm-2•nm-1 (+/- 25%) 6-point check
- Peak Wavelength: 445-470 nm
- LED Module Estimated Life: Under continuous use, tested at room temperature, a typical LED module will run > 50,000 hours before the light intensity drops 25%
- Sound Level: ≤ 44 dB(A) at 1 meter
- X-Ray: X-Ray Compatible
Physical Specifications
- Light Box (W x H x L): 16.5 x 21 x 17.5 cm
- Light Box Weight (Excluding Fiber Optic Pad): < 1.7 kg
- Light Pad Weight: < 0.6 kg (large or small)
- Light Pad, Size Small: 20 x 25 cm (light-emitting area)
- Light Pad, Large: 25 x 30 cm (light-emitting area)
- Light Pad Cable Length: 137 ± 5 cm
